Brand Name :
Mimaki
Model Number :
JFX200-2513 EX
Certification :
CE
Place of Origin :
Japan
MOQ :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 Sets Per 1 Month
Delivery Time :
7-15 Working Days
Packaging Details :
Standard Packaging
Head :
On-demand Piezo head (Array of 3 heads stagger)
Print resolution :
300, 450, 600, 900, 1,200dpi
Ink Type :
UV curable ink : LUS-120 (C, M, Y, K, W, Cl) UV curable ink : LUS-150 (C, M, Y, K, Lc, Lm, W) UV curable ink : LUS-211 (C, M, Y, K, W, Cl) *Only available in some regions. UV curable ink : LUS-350 (C, M, Y, K, W, Cl) UV curable ink : LH-100 (C, M, Y, K, Lc
Ink Ink Supply system :
1liter bottle, 250ml bottle (LH-100, LUS-120, PR-200 only) *2
Ink circulation system *3 :
White ink circulation using Mimaki Circulation Technology (MCT)
Maximum diagram dimensions (W×D) :
2,500×1,300 mm (98.4×51.2")
Media Dimensions (W×D) :
2,500×1,300 mm (98.4×51.2")
Media Height :
Max. 50 mm (2.0")
Media Weight :
Less than 50 kg/m2 (10.2 lb./ft2), non concentrated load
Media absorption :
Blower adsorption type + foot switch
Number of absorption area partitions :
2 partitions (X-axis direction)
Curing device :
LED-UV system
Interface :
USB2.0, Ethernet
Safety standard :
VCCI class A, CE mark, CB report, U.S. safety standard UL (UL62368-1), RoHS Directive, FCC Class A, Machinery directive, EAC, RCM
Input power supply :
Single phase, AC 200-240 V, 50/60 Hz, less than 12 A
Power consumption :
Less than 2.88 kVA
Assembled Dimensions (W×D×H) :
4,400×2,450×1,250 mm (173.2×96.4×49.2")
Weight :
650 kg (1,433 lbs.)
product name :
Flatbed UV Printer
Brand :
MIMAKI
feature :
High precision
